We design and manufacture nozzles with precision spraying capabilities that ensure even distribution of the material being sprayed, as well as precise control of the spray angle and thickness of the coating. This precise spraying capability makes the coating process more efficient and accurate, resulting in increased productivity and product quality.
Whether you're spraying in automotive, aerospace, oil and gas, or other applications, a tungsten carbide nozzle plays a vital role in spraying precision. They can improve spraying results, reduce material waste and save costs, while also protecting spraying equipment and extending its life.
Excellent characteristics of tungsten carbide nozzle:
1. Precise control of spraying.
2. Good abrasion resistance to withstand abrasive friction.
3. Can be in contact with corrosive media.
4. Size and shape can be customized.
Cobalt Binder Grades
| Grade | Binder (Wt %) | Density (g/cm3) | Hardness (HRA) | TRS (≥N/mm²) |
| YG6 | 6 | 14.8 | 90.0 | 1520 |
| YG6X | 6 | 14.9 | 91.0 | 1450 |
| YG6A | 6 | 14.9 | 92.0 | 1540 |
| YG8 | 8 | 14.7 | 89.5 | 1750 |
| YG12 | 12 | 14.2 | 88.0 | 1810 |
| YG15 | 15 | 14.0 | 87.0 | 2050 |
| YG20 | 20 | 13.5 | 85.5 | 2450 |
| YG25 | 25 | 12.1 | 84.0 | 2550 |
Nickel Binder Grades
Grade | Binder (Wt %) | Density (g/cm3) | Hardness (HRA) | TRS (≥N/mm²) |
YN6 | 6 | 14.7 | 89.5 | 1460 |
YN6X | 6 | 14.8 | 90.5 | 1400 |
YN6A | 6 | 14.8 | 91.0 | 1480 |
YN8 | 8 | 14.6 | 88.5 | 1710 |
