| Tungsten carbide material specification | |||||
| Grade | Binder (Wt %)Cobalt | Density (g/cm3) | Hardness (HRA) | TRS (>N/mm²) | Grain Size(μm) |
| YG6 | 5.8-6.3 | 14.6-15.0 | 89.5-91 | 1800 | 0.8-2.0 |
| YG6X | 5.8-6.3 | 14.4-14.7 | 90.5-91.5 | 1650 | 0.6-1.0 |
| YG8 | 7.5-8.2 | 14.4-14.7 | 89.0-90.5 | 2200 | 1.0-1.5 |
| YG11 | 11.0-11.5 | 14.2-14.4 | 87.0-88.5 | 2800 | 1.0-2.0 |
| YG11C | 11.0-11.5 | 14.2-14.4 | 86.0-88.0 | 3000 | 1.0-2.5 |
| YG15 | 14.5-15 | 13.9-14.0 | 86.0-88.0 | 3300 | 1.0-2.0 |
| YG20 | 20.0-20.5 | 13.2-13.5 | 84.0-85.0 | 3400 | 1.0-2.0 |
| YG20C | 20.0-20.5 | 13.2-13.5 | 83.0-85.0 | 3600 | 1.0-2.5 |
| K05VF | 4.5-5.0 | 14.6-15.0 | 92.5-93.0 | 1500 | 0.6-1.0 |
| K10VF | 5.5-6.2 | 14.5-14.7 | 91.5-92.5 | 1550 | 0.6-1.0 |
| K20VF | 7.5-8.0 | 14.5-14.7 | 90.5-91.5 | 1800 | 0.6-1.0 |
| Grade | Binder (Wt %)Nickel | Density (g/cm3) | Hardness (HRA) | TRS (>N/mm²) | Grain Size(μm) |
| YN6 | 5.5-6.2 | 14.6-15.0 | 89.5-90.5 | 1800 | 0.8-2.0 |
| YN6X | 5.9-6.5 | 14.5-14.9 | 89.4-91 | 1750 | 0.8-1.8 |
| YN6A | 5.9-6.5 | 14.5-14.8 | 89.5-91.5 | 1850 | 0.8-1.8 |
| YN7 | 6.8-7.2 | 14.4-14.8 | 89.0-90.0 | 1900 | 0.8-1.6 |
| YN8 | 7.8-8.3 | 14.5-14.8 | 89.0-90.0 | 2200 | 0.8-2.0 |
| YN12 | 11.5-12.2 | 14.0-14.4 | 87.5-88.5 | 2600 | 0.8-2.0 |
| YN15 | 14.5-15.2 | 13.7-14.2 | 86.5-88.0 | 2800 | 0.6-1.5 |
In the process of oil exploration, it is generally in a fairly extreme working environment, so the nozzle calls for to take on the high-speed shock impact of high-pressure abrasives throughout the functioning procedure, so it is a whole lot more prone to put on and also failing. Average materials are prone to thermal deformation or splitting, requiring constant substitute of nozzles, which decreases job efficiency. Tungsten nozzles can better improve this scenario as a result of their high strength, high strength and likewise exceptional wear as well as corrosion resistance.This also makes tungsten carbide nozzles the most commonly used nozzles in today's society.
Advantage of Langsun Carbide Tungsten Carbide Nozzle:
1. It has super high strength and hardness, excellent wear resistance and corrosion resistance, and can be applied to various scenarios
2. Made with the best raw material formula, the product performance is excellent and stable
3. Can make nozzles of various complex shapes, support customized products
4. The product has been strictly inspected and absolutely meets the requirements for use
5. Own multiple processing plants, excellent supply capacity
6. Flexible payment method and great price advantage
Service:
1. Help customers choose the most suitable material grade for customers
2. Can customize the most suitable products for customers
3. Products can be customized according to the drawings provided by customers
4. Solve any problems raised by customers
5. If there is a problem with the product during the warranty period, it can be replaced
