A tungsten carbide nozzle is a nozzle made of tungsten carbide, a compound consisting of tungsten (W) and carbon (C). Tungsten carbide nozzles are valued for their superior durability, longevity and ability to withstand harsh working environments. Tungsten carbide nozzles are favored in industrial settings where abrasive materials or corrosive environments are present. One of the most notable applications for tungsten carbide nozzles is in sandblasting or shot peening equipment.
Industries such as oil and gas, metal processing, mining and automotive
Features of tungsten carbide nozzles:
1. High hardness, made of one of the hardest materials
2. Extreme wear resistance
3. High strength, high resistance to deformation
4. Strong durability
5. Excellent thermal stability, high melting point
Choose Langsun Carbide:
1.100% selected fine tungsten carbide powder
2.HIP sintering
3. Various sizes and specifications
4. Fine workmanship, high precision
5. Accept small batch orders and sample trial
Ningbo Langsun Tungsten Carbide Co., using scientific and precise processing equipment and HIP sintering process to produce tungsten carbide nozzles, our tungsten carbide nozzles are of excellent quality and affordable. Tungsten carbide nozzles are available in a variety of sizes, including custom sizes. We can provide various types of tungsten carbide nozzles, including tungsten carbide air nozzles, tungsten carbide sandblasting nozzles, tungsten carbide gas nozzles and various non-standard industrial nozzles.
| Tungsten carbide material specification | |||||
| Grade | Binder (Wt %)Cobalt | Density (g/cm3) | Hardness (HRA) | TRS (>N/mm²) | Grain Size(μm) |
| YG6 | 5.8-6.3 | 14.6-15.0 | 89.5-91 | 1800 | 0.8-2.0 |
| YG6X | 5.8-6.3 | 14.4-14.7 | 90.5-91.5 | 1650 | 0.6-1.0 |
| YG8 | 7.5-8.2 | 14.4-14.7 | 89.0-90.5 | 2200 | 1.0-1.5 |
| YG11 | 11.0-11.5 | 14.2-14.4 | 87.0-88.5 | 2800 | 1.0-2.0 |
| YG11C | 11.0-11.5 | 14.2-14.4 | 86.0-88.0 | 3000 | 1.0-2.5 |
| YG15 | 14.5-15 | 13.9-14.0 | 86.0-88.0 | 3300 | 1.0-2.0 |
| YG20 | 20.0-20.5 | 13.2-13.5 | 84.0-85.0 | 3400 | 1.0-2.0 |
| YG20C | 20.0-20.5 | 13.2-13.5 | 83.0-85.0 | 3600 | 1.0-2.5 |
| K05VF | 4.5-5.0 | 14.6-15.0 | 92.5-93.0 | 1500 | 0.6-1.0 |
| K10VF | 5.5-6.2 | 14.5-14.7 | 91.5-92.5 | 1550 | 0.6-1.0 |
| K20VF | 7.5-8.0 | 14.5-14.7 | 90.5-91.5 | 1800 | 0.6-1.0 |
| Grade | Binder (Wt %)Nickel | Density (g/cm3) | Hardness (HRA) | TRS (>N/mm²) | Grain Size(μm) |
| YN6 | 5.5-6.2 | 14.6-15.0 | 89.5-90.5 | 1800 | 0.8-2.0 |
| YN6X | 5.9-6.5 | 14.5-14.9 | 89.4-91 | 1750 | 0.8-1.8 |
| YN6A | 5.9-6.5 | 14.5-14.8 | 89.5-91.5 | 1850 | 0.8-1.8 |
| YN7 | 6.8-7.2 | 14.4-14.8 | 89.0-90.0 | 1900 | 0.8-1.6 |
| YN8 | 7.8-8.3 | 14.5-14.8 | 89.0-90.0 | 2200 | 0.8-2.0 |
| YN12 | 11.5-12.2 | 14.0-14.4 | 87.5-88.5 | 2600 | 0.8-2.0 |
| YN15 | 14.5-15.2 | 13.7-14.2 | 86.5-88.0 | 2800 | 0.6-1.5 |
