Type | Dimension(mm) | |||
l | t | s | r0 | |
E210 | 10.8 | 9 | 2 | 1 |
E211 | 11.8 | 10 | 2.5 | 1 |
E213 | 13 | 11 | 2.5 | 1 |
E214 | 14 | 12 | 2.5 | 1 |
E215 | 15 | 13 | 2.5 | 1 |
E216 | 16 | 14 | 3 | 1 |
E217 | 17 | 15 | 3 | 1.5 |
E218 | 18 | 16 | 3 | 1.5 |
E219 | 19 | 17 | 3 | 1.5 |
E220 | 20 | 18 | 3.5 | 1.5 |
E221 | 21 | 18 | 3.5 | 1.5 |
E222 | 22 | 18 | 3.5 | 1.5 |
E223 | 23 | 18 | 4 | 1.5 |
E224 | 24 | 18 | 4 | 1.5 |
E225 | 25 | 22 | 4.5 | 2 |
E226 | 26 | 22 | 4.5 | 2 |
E227 | 27.5 | 22 | 4.5 | 2 |
E228 | 28.5 | 22 | 4.5 | 2 |
E229 | 29.5 | 24 | 5 | 2 |
E230 | 30.5 | 24 | 5 | 2 |
E231 | 31.5 | 24 | 5 | 2 |
E233 | 33.5 | 26 | 5 | 2 |
E236 | 36.5 | 26 | 5 | 2 |
E239 | 39.5 | 26 | 5 | 2 |
E242 | 42 | 28 | 6 | 2 |
E244 | 44 | 28 | 6 | 2 |
E247 | 47 | 28 | 6 | 2 |
E250 | 50 | 30 | 6 | 2 |
E252 | 52 | 30 | 6 | 2 |
