Tungsten carbide nozzles are industrial components that are frequently used in applications requiring high-precision spraying and in abrasive blasting equipment. Tungsten carbide nozzles are highly regarded for their extreme hardness, wear resistance and ability to withstand harsh environments, making them ideal for many demanding industrial applications.
Applications of tungsten carbide nozzles:
Coating, surface treatment, spraying, semiconductor manufacturing, etc.
Features of tungsten carbide nozzles:
1. High wear resistance
2. High precision, precise size
3. High corrosion resistance
4. Ability to withstand harsh conditions
5. High hardness, high strength
choose us:
1.100% tungsten carbide raw material to produce tungsten carbide nozzle
2.HIP sintering technology
3. Various sizes and specifications are available
4. Reasonable price and fast delivery
5. Accept small order
Ningbo Langsun Tungsten Carbide Co., tungsten carbide nozzles are available in various shapes and sizes, we can provide various types of tungsten carbide nozzles, such as gas nozzle , fuel nozzle , sandblasting nozzle and so on. We use advanced manufacturing technology and strict quality control process, the design and manufacture of tungsten carbide nozzles can be very precise. The tungsten carbide nozzles we supply are of reliable quality and long service life.
| Tungsten carbide material specification | |||||
| Grade | Binder (Wt %)Cobalt | Density (g/cm3) | Hardness (HRA) | TRS (>N/mm²) | Grain Size(μm) |
| YG6 | 5.8-6.3 | 14.6-15.0 | 89.5-91 | 1800 | 0.8-2.0 |
| YG6X | 5.8-6.3 | 14.4-14.7 | 90.5-91.5 | 1650 | 0.6-1.0 |
| YG8 | 7.5-8.2 | 14.4-14.7 | 89.0-90.5 | 2200 | 1.0-1.5 |
| YG11 | 11.0-11.5 | 14.2-14.4 | 87.0-88.5 | 2800 | 1.0-2.0 |
| YG11C | 11.0-11.5 | 14.2-14.4 | 86.0-88.0 | 3000 | 1.0-2.5 |
| YG15 | 14.5-15 | 13.9-14.0 | 86.0-88.0 | 3300 | 1.0-2.0 |
| YG20 | 20.0-20.5 | 13.2-13.5 | 84.0-85.0 | 3400 | 1.0-2.0 |
| YG20C | 20.0-20.5 | 13.2-13.5 | 83.0-85.0 | 3600 | 1.0-2.5 |
| K05VF | 4.5-5.0 | 14.6-15.0 | 92.5-93.0 | 1500 | 0.6-1.0 |
| K10VF | 5.5-6.2 | 14.5-14.7 | 91.5-92.5 | 1550 | 0.6-1.0 |
| K20VF | 7.5-8.0 | 14.5-14.7 | 90.5-91.5 | 1800 | 0.6-1.0 |
| YN6 | 5.5-6.2 | 14.6-15.0 | 89.5-90.5 | 1800 | 0.8-2.0 |
| YN6X | 5.9-6.5 | 14.5-14.9 | 89.4-91 | 1750 | 0.8-1.8 |
| YN6A | 5.9-6.5 | 14.5-14.8 | 89.5-91.5 | 1850 | 0.8-1.8 |
| YN7 | 6.8-7.2 | 14.4-14.8 | 89.0-90.0 | 1900 | 0.8-1.6 |
| YN8 | 7.8-8.3 | 14.5-14.8 | 89.0-90.0 | 2200 | 0.8-2.0 |
| YN12 | 11.5-12.2 | 14.0-14.4 | 87.5-88.5 | 2600 | 0.8-2.0 |
| YN15 | 14.5-15.2 | 13.7-14.2 | 86.5-88.0 | 2800 | 0.6-1.5 |
